22309E Spherical Roller Bearings 40X100X36mm Double Row

🔍

22309E

Bore Diameter:45 mm

Outside Diameter:100 mm

Width:36 mm

Weight:1.4 kg

Min. Order:1 Piece

The 22309E bearing is a Spherical Roller Bearings with an inner diameter of 45 mm , an outer diameter of 100 mm, a width of 36 mm. It typically uses P0 grade precision tolerances and features a steel cage, Its dynamic radial rated load is approximately 190 kN, its static radial rated load is approximately 183 kN. It uses normal standard radial clearance, none type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Long life

Application: Chemical equipment accessories, homogenizing equipment,automatic welding machines,CNC ,machine tools.

Dimensions:

Inside Diameter:

45 mm

Outside Diameter:

100 mm

Thickness:

36 mm

Weight:

1.4 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

190 kN

Static load Capacity, Radial (Cor):

183 kN

Fatigue Load Limit, Axial:

19.6 kN

Reference speed (Grease rpm):

5300 r/min

Limiting speed (Oil rpm):

7 000 r/min

Specifications:

HS Code:

8482.10.50.28

Structure:

Spherical

Number of Rows:

Double

Demensions:

40mmX100mmX36mm

Brand:

HSN

Radial Clearance Trade No.:

normal

Precision Rating:

Vibration:

Bearing Material:

GCr15

Cage material:

steel

Seals Type:

none

Bore Type:

45mm

Series:

Spherical Roller Bearings

Lubrication Hole Type:

3 mm

Rolling Element:

bearing steel

Transaction Information:

Transport Package:

plastic+anti-rust paper+box+wooden box

Service:

Customized

Shipping Ways:

As clients' request

Country of Origin:

Shandong, China

Quality Control:

All we can promise

Stock:

100 Piece

Production Capacity:

10000 Piece/Pieces per Month

Port:

Jinan Port

Payment term:

Paypal/Western Union/TT. etc.

Delivery time:

3-5 working days after receiving your payment

Detailed description

22309E stands for a roller bearing with a size of 40mm*100mm*36mm, its precision rating is P0. 22309E spherical roller bearings were certified by ISO9001:2008.

Application

22309E spherical roller bearings can be used widely as following:

1. Chemical equipment accessories, homogenizing equipment.

2. Automatic welding machines,CNC ,machine tools.

3. Geological and mineral exploration,mineral processing.

4. And other fields.

Parameters

Model:22309E

Type: Roller

Bore diameter(D): 45 mm

Outside diameter(d): 100mm

Width(B): 36mm

Weight: 1.4kg

Shoulder diameter of inner ring(d2): 57.6 mm

Shoulder/recess diameter of outer ring(D1): 83.4 mm

Width of lubrication groove(b): 6 mm

Diameter of lubrication hole(K): 3 mm

Chamfer dimension(r1,2): min.1.5 mm

Basic dynamic load rating(C): 190 kN

Basic static load rating(C0): 183 kN

Fatigue load limit(Pu): 19.6 kN

Reference speed:5 300 r/min

Limiting speed:7 000 r/min

Limiting value(e):0.37

Axial load factor(Y1):1.8

Axial load factor(Y2):2.7

Axial load factor(Y0):1.8

Precision Rating:P0

Hardness: HRC58-62

Structure: Spherical

PACKAGE: plastic+anti-rust paper+box+wooden box

Greese: SRL
