222S.400 Bore 101.6 Mm, Spherical Roller Bearings Split, Inch Sizes, Solid Polyamide Cage (Plastic Cage)

🔍

222S.400

Bore Diameter:101.6 mm

Outside Diameter:200 mm

Width:92 mm

Weight:9.93 kg

Min. Order:1 Piece

The 222S.400 bearing is a Spherical roller bearings split, inch sizes with an inner diameter of 101.6 mm , an outer diameter of 200 mm, a width of 92 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 359201 N, its static radial rated load is approximately 458752 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

101.6 mm

Outside Diameter:

200 mm

Thickness:

92 mm

Weight:

9.93 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

359201 N

Static load Capacity, Radial (Cor):

458752 N

Fatigue Load Limit, Radial:

38476 N

Limiting speed (Oil rpm):

1572

Specifications:

Old Designations:

222S400

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

TVPA = Solid polyamide cage (Plastic cage)

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to up +200 °C

Series:

222S

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	222S.400
Interchangeable	FAG 222S.400
Bearing Type	Spherical roller bearings split, inch sizes
Splitted	S. = Split bearing inch
Bearing Mass - m [lb]	21.892
Rows NO.	Double row
Cage	TVPA = Solid polyamide cage (Plastic cage)
Design Type	E1A = without central rip
Replacement Bearing	22222K
Replacement Adapter sleeve	SNW22X0400 , H322X400
Housing	SAF522/4 , SNV200
Dimension
Inside - d φ [mm]	101.6
Inside - d φ [inch]	4
Outside - D Φ [inch]	7.874
Width - B [inch]	3.622
Width - C [inch]	2.087
r(min.) [inch]	0.083
Performance
Radial Dynamic - C_r [lbf]	80748
Radial static - C_0r [lbf]	103127
Radial Fatigue - C_ur [lbf]	8649
Limiting speed - n_G [min^–1]	1572
Permissible axial load - F_a(max.) [lbf]	3089
Screw tightening torque - M_i [Nm]	35
Screw tightening torque - M_a [Nm]	14
Coefficient
e	0.24
Y₁	2.84
Y₂	4.23
Y₀	2.78
