222S.308 Bore 88.9 Mm, Spherical Roller Bearings Split, Inch Sizes, Solid Polyamide Cage (Plastic Cage)

🔍

222S.308

Bore Diameter:88.9 mm

Outside Diameter:180 mm

Width:76 mm

Weight:6.77 kg

Min. Order:1 Piece

The 222S.308 bearing is a Spherical roller bearings split, inch sizes with an inner diameter of 88.9 mm , an outer diameter of 180 mm, a width of 76 mm. GCr18Mo, G20Cr2Ni4A rings, GCr18Mo, G20Cr2Ni4A rolling mlement. Its dynamic radial rated load is approximately 284121 N, its static radial rated load is approximately 359172 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

88.9 mm

Outside Diameter:

180 mm

Thickness:

76 mm

Weight:

6.77 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

284121 N

Static load Capacity, Radial (Cor):

359172 N

Fatigue Load Limit, Radial:

31420 N

Limiting speed (Oil rpm):

1799

Specifications:

Old Designations:

222S308

Structure:

Spherical Roller Bearings

Number of Rows:

Double row

Bearing Material:

GCr18Mo, G20Cr2Ni4A

Cage Type:

TVPA = Solid polyamide cage (Plastic cage)

Rolling Mlement Material:

GCr18Mo, G20Cr2Ni4A

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to up +200 °C

Series:

222S

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

Part Number	222S.308
Interchangeable	FAG 222S.308
Bearing Type	Spherical roller bearings split, inch sizes
Splitted	S. = Split bearing inch
Bearing Mass - m [lb]	14.925
Rows NO.	Double row
Cage	TVPA = Solid polyamide cage (Plastic cage)
Design Type	E1A = without central rip
Replacement Bearing	22220K
Replacement Adapter sleeve	SNW20X0308 , H320X308
Housing	SAF520/3.1/2 , SNV180
Dimension
Inside - d φ [mm]	88.9
Inside - d φ [inch]	3 1/2
Outside - D Φ [inch]	7.087
Width - B [inch]	2.992
Width - C [inch]	1.811
r(min.) [inch]	0.083
Performance
Radial Dynamic - C_r [lbf]	63870
Radial static - C_0r [lbf]	80741
Radial Fatigue - C_ur [lbf]	7063
Limiting speed - n_G [min^–1]	1799
Permissible axial load - F_a(max.) [lbf]	1695
Screw tightening torque - M_i [Nm]	14
Screw tightening torque - M_a [Nm]	14
Coefficient
e	0.23
Y₁	2.9
Y₂	4.31
Y₀	2.83
