191.20.2000.990.41.1502 Three-rows Roller Slewing Bearing

🔍

191.20.2000.990.41.1502

Bore Diameter:1853 mm

Outside Diameter:2236.8 mm

Width:132 mm

Weight:912 kg

The 191.20.2000.990.41.1502 bearing is a Slewing bearing / Slewing ring with an inner diameter of 1853 mm , an outer diameter of 2236.8 mm, a width of 132 mm. It typically uses P0/P6/P5 grade precision tolerances and Rubber/Fluororubber seals type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

1853 mm

Outside Diameter:

2236.8 mm

Thickness:

132 mm

Weight:

912 KG

Specifications:

Structure:

Three-rows Roller Slewing Bearing

Precision Rating:

P0/P6/P5

Bearing Material:

42CrMo/50Mn

Seals Type:

Rubber/Fluororubber seals

Transaction Information:

Payment term:

30% T/T in Advance, the balance 70%TT before shipp

Delivery time:

Detailed description

Bearing model :191.20.2000.990.41.1502 Three-rows roller slewing Bearing Size:1853x2236.8x132mm
Inner Diameter ( ID ) :1853 mm
Outer diameter (OD) :2236.8 mm
Width/Height : 132
Outer Gear Teeth
Moudle: M=16
NO. of teeth: Z=137
Pressure Angle: a=20°
Modification coefficient: X=+0.5
Material :42CrMo/50Mn
Seals type: Rubber/Fluororubber seals
Lubrication: Grease

They are widely used in hoister transportation, mining, architecture, harbor machinery, shipping mechanism, radar machinery of high accuracy, and large-scale rotary devices on aspect of missile launcher.

Share this product to:

Let more people see your product

How can you buy 191.20.2000.990.41.1502 Three-rows Roller Slewing Bearing on the Internet?
High quality 191.20.2000.990.41.1502 ( 912 kg Mass, ID: 1853 mm OD: 2236.8 mm WD: 132 mm , P0/P6/P5 Accuracy Class , 42CrMo/50Mn Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 191.20.2000.990.41.1502. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
