160/530-M Deep Groove Ball Bearings, Single Row, Open Design, Self-retaining

🔍

160/530-M

Bore Diameter:530 mm

Outside Diameter:780 mm

Width:80 mm

Weight:142 kg

Min. Order:1 Piece

The 160/530-M Single-row deep groove ball bearings are widely used in various rotating machinery, such as: electric motors (general-purpose motors, household appliances), automotive wheel hubs, industrial gearboxes, agricultural machinery, pumps and compressors, conveying equipment, and power tools.

The 160/530-M bearing is a Deep groove ball bearings, Single row , open design, self-retaining with an inner diameter of 530 mm , an outer diameter of 780 mm, a width of 80 mm. GCr15SiMn rings, Its dynamic radial rated load is approximately 509939 N, its static radial rated load is approximately 999947 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

530 mm

Outside Diameter:

780 mm

Thickness:

80 mm

Weight:

142 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

509939 N

Static load Capacity, Radial (Cor):

999947 N

Fatigue Load Limit, Radial:

22470 N

Reference speed (Grease rpm):

900

Limiting speed (Oil rpm):

1683

Specifications:

Old Designations:

160/530M

Structure:

Single row deep groove ball bearings

Number of Rows:

Radial Clearance Trade No.:

Bearing Material:

GCr15SiMn

Cage Type:

M = Solid brass cage, ball-guided

Seals Type:

Open

Bore Type:

Z = Cylindrical bore

Operating Temperature:

-30 to 200 °C

Series:

160..-M

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

160/530-M bearings ( 530 mm x 780 mm x 80 mm) have the advantages of simple structure, ability to withstand radial and bidirectional axial loads, low friction, and high speed, it is suitable for high-speed, low-noise applications, and are therefore widely used in the Motors, home appliances, automobiles, pumps, compressors, conveying equipment and general industrial machinery.

Part Number	160/530-M
Reference From	FAG 160/530-M
Bearing Type	Deep groove ball bearings, Single row , open design, self-retaining
Series	160..-M
Sealing	Open
Cage	M = Solid brass cage, ball-guided
Radial internal clearances	CN
Weight [lb]	313.053
C_r Radial Dynamic [lbf]	114634
C_0r Radial static [lbf]	224788
C_ur Radial Fatigue [lbf]	5051
n_B Reference speed [rpm]	900
n_G Limiting speed [rpm]	1683
Operating temperature - T(min) [°C]	-30
Operating temperature - T(max) [°C]	200
d φ Inside [inch]	20.866
D Φ Outside [inch]	30.709
B Width [inch]	3.150
r(min.) [inch]	0.236
D₁ [inch]	27.114
d₁ [inch]	24.594
Mounting dimensions
d_a(min.) [inch]	21.772
D_a(max.) [inch]	29.803
r_a(max.) [inch]	0.197
Coefficient - F₀ [inch]	16.3

The 160/530-M Single-row deep groove ball bearings mainly consist of an inner ring, outer ring, steel balls, and a cage. The raceways are deep grooves, with the steel balls making four-point contact with the raceways. The inner and outer rings can be separable or integrated. They are available in various forms, including open, with dust covers, and with seals.

Single-row deep groove ball bearings have a simple structure and are the most widely used. They can simultaneously withstand radial loads and bidirectional axial loads, making them suitable for high-speed operation. They have a low coefficient of friction, low noise, and are easy to install and maintain. Versions with seals or dust covers effectively prevent contaminant intrusion and are suitable for various operating conditions.
