15590-15520 Tapered Roller Bearings With Long Life

🔍

15590-15520

Bore Diameter:28.575 mm

Outside Diameter:57.15 mm

Width:17.463 mm

Min. Order:1 Piece

The 15590-15520 bearing is a Tapered Roller Bearings with an inner diameter of 28.575 mm , an outer diameter of 57.15 mm, a width of 17.463 mm. It typically uses p0/p6/p5/p4/p2 grade precision tolerances and features a Steel cage, Steel balls, Steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 46000, its static radial rated load is approximately 50100. It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: High speed, low voice & long life.

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

28.575 mm

Outside Diameter:

57.15 mm

Thickness:

17.463 mm

Chamfer (R):

3.6

Cone Width (B):

17.463

Cup Width (C):

13.495

Chamfer (r):

1.52

Performance Data:

Dynamic load Capacity, Radial (Cr):

46000

Static load Capacity, Radial (Cor):

50100

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Number of Rows:

Single

Demensions:

28.575 *57.15*17.463

Brand:

Z&K/Neutral / OEM

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Precision Rating:

p0/p6/p5/p4/p2

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Bearing Material:

Bearing Steel

Cage material:

Steel

Ball Material:

Steel

Roller Material:

Steel

Series:

15000

Cone Number:

15590

Cup Number:

15520

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

1000 Piece

Production Capacity:

10000/year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

15590-15520 Tapered Roller Bearings With Long Life
15590-15520 Tapered Roller Bearings With Long Life
Bearing NO.:	15590-15520	Weight(kg):	0.3
Material:	Bearing steel	Ab (mm):	2.5
Series:	15000	Db(mm):	51.05
Cone Part Number:	15590	Da (mm):	53.1
Cup Part Number:	15520	a:	-5.1
Bore (mm)d:	28.575	R(mm):	3.6
Cup Outer Diameter(mm)D:	57.15	r (mm):	1.52
Cone Width(mm)B:	17.463	Aa(mm):	0.8
Cup Width (mm)C:	13.495	da(mm):	33.5
Bearing Width (mm)T:	17.463	db (mm):	39.5
Dynamic load rating (C90)N:	11900	K:	1.69
Dynamic load rating (C₁)N:	46000	G1:	12.7
Static Radial Rating(CO)N:	50100	G2:	10.3
Dynamic Thrust Ratin(Ca₉₀)N:	7070	Cg:	0.0577
Applicable Industries:	Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company	Contact Bonnie:	Email:[email protected]
Applicable Industries:		Contact Bonnie:	Email:[email protected]

Share this product to:

Let more people see your product

How can you buy 15590-15520 Tapered Roller Bearings With Long Life on the Internet?
High quality 15590-15520 ( ID: 28.575 mm OD: 57.15 mm WD: 17.463 mm , 15000 Series , Single Rows , C0 C2 C3 C4 C5 Radial Clearance , p0/p6/p5/p4/p2 Accuracy Class , Bearing Steel Material , 46000 Radial dynamic , 50100 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 15590-15520. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
