150TVL701 Single-row Angular Contact Thrust Ball Bearing

🔍

150TVL701

Bore Diameter:381 mm

Outside Diameter:520.7 mm

Width:84.125 mm

Weight:50.2 kg

Min. Order:1 Piece

The 150TVL701 Thrust angular contact ball bearings are mainly suitable for applications requiring high speed, low friction, and simultaneous axial and certain radial loads, such as fluid control valves, machine tool worktables and spindles, and rotary tables in the oil and gas drilling industry.

The 150TVL701 bearing is a Single-row angular contact thrust ball bearing with an inner diameter of 381 mm , an outer diameter of 520.7 mm, a width of 84.125 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic axial rated load is approximately 508118 N, its static axial rated load is approximately 2295376 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

381 mm

Outside Diameter:

520.7 mm

Thickness:

84.125 mm

Weight:

50.2 KG

Dynamic load Capacity, axial:

508118 N

Static load Capacity, axial:

2295376 N

Specifications:

Structure:

Thrust Angular Contact Ball Bearings

Number of Rows:

One

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Metric

Series:

TVL

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

150TVL701 bearings ( 381 mm x 520.7 mm x 84.125 mm) have the advantages of Composite load, high speed, high rigidity, and are therefore widely used in the rotary tables of oil and gas drilling rigs.

Part Number	150TVL701
Design type	TVL: Single-row angular contact construction
Bearing Type	Single-row angular contact thrust ball bearing
Interchangeable	TIMKEN 150TVL701
Manufacturer Part Code	150 TVL 701
Series	TVL
Units	Metric
Tolerance class	PN (ABEC-1)
C_0a Axial Static [lbf]	516000
C_a Axial Dynamic [lbf]	114224
d φ Inside [inch]	15.0000
D Φ Outside [inch]	20.5000
T Width [inch]	3.3120
r Fillet Radius [inch]	0.1890
d₁ [inch]	16.5000
D₁ [inch]	19.0000
E (Max) Shoulder Diameter Housing [inch]	17.7480
H (Min) Shoulder Diameter Shaft [inch]	17.7480
Dowel Pin (Pin Dia.) [inch]	0.5000
Hole Location (Small Bore Ring) [inch]	8.1260
Hole Location (Large Bore Ring) [inch]	9.6260
Weight [lb]	110.6709

The 150TVL701 Thrust angular contact ball bearings are mainly composed of precision-ground steel balls, hardened and ground steel raceways, and a brass (or bronze) cage. Their core characteristic is their ability to simultaneously withstand axial thrust loads and a certain amount of radial load, and they also feature low friction, quiet operation, and suitability for high-speed operation.
